EVT400

Description

Low DC voltage, and invisible

Components selected from world-class brands

Individual MPPT for each module

Adapts to any system size and optimizes space.

Hand-in-hand design, fewer add-ons, and fast installation.

Long 25 years lifetime, up to 15 years warranty.

Module-level online smart monitoring

Smart*: Smart monitoring devices are optional at additional cost.

Input Data(DC)
Recommended Input Power Range(STC)	180W-550W+
Max.DC Input(V)	60V
Isc PV (Absolute Max.)(A)	25A
Operating Range(V)	16V-60V
Max.lnput Current(A)	14A
MPPT Voltage Range(V)	22V-48V
Output Data(AC)
Normal Voltage(Vac)	189-260V
Current(Max.continuous)(A)	1.81A
Frequency(Hz)	475-525H2/57.5-62.5HZ
Power(Max.continuous)(W)	400W
Power Factor/Rated(default)	"+/- 0.90"
Total Harmonic Distortion	<3%
Maximum Units Per Branch (12AWG Cable)	14Units
Efficiency
Peak Inverter Efficiency	96.50%
MPPT Efficiency	99.90%
Nighttime Power Consumption	<100mW
Features
Communication	PLCC(Power Line Carrier Communication)WiFi
Compliance	VDE-ARN 4105EC/EN61000IEC/EN62109-112 EN50549-112019 TOR2019.C10/11:2019.UTE C15-712-1:2013.VFR 2019
Warranty	15 years(20 years optional)
Others
Ingress Protection(lP)	IP67
Protective Class	Classel
Temperature ( C)	-40°Cto+65°C
Relative Humidity	0%-98%
Overvoltage Category	OVCIII (AC Main)OVCII (PV)
Inverter Isolation	High Frequency lsolated
Weight	1.8kg
Dimensions(WHD)	163mm216mm27mm
