Description
![security-green security-green](https://cosysolar.com/wp-content/uploads/elementor/thumbs/security-green-qc3zu7tjw7lgxrgixfj4bswf6jgwcba2xgityliqq8.png)
Safe
Low DC voltage, and invisible
![quality-green quality-green](https://cosysolar.com/wp-content/uploads/elementor/thumbs/quality-green-qceayaz77kjruh6peei2afiu5laptpwh3r4jesdvio.png)
Quality
Components selected from world-class brands
![optimization-green optimization-green](https://cosysolar.com/wp-content/uploads/elementor/thumbs/optimization-green-qceb3i12zlnu0vn025ctkmbkd9ordhj25gy5wuoj4g.png)
Optimization
Individual MPPT for each module
![puzzle-green puzzle-green](https://cosysolar.com/wp-content/uploads/elementor/thumbs/puzzle-green-qceb7llqsl9unnon4f58y32xmrhdxysx1rde9alpzk.png)
Flexibility
Adapts to any system size and optimizes space.
![plug-and-play-green plug-and-play-green](https://cosysolar.com/wp-content/uploads/elementor/thumbs/plug-and-play-green-qceblmd2qmgtu9bg8zbwn1pgmodhrfgrz5p4yvtb68.png)
Plug & Play
Hand-in-hand design, fewer add-ons, and fast installation.
![diamond-green diamond-green](https://cosysolar.com/wp-content/uploads/elementor/thumbs/diamond-green-qcebxsdv7f4g4jn778o1wz69g8ejedrozdpeltrumo.png)
15 Years
Long 25 years lifetime, up to 15 years warranty.
![idea-green idea-green](https://cosysolar.com/wp-content/uploads/elementor/thumbs/idea-green-qced2u05mzb73k0vizdksmav9y3jikpqmj8p0swyxc.png)
Smart
Module-level online smart monitoring
Smart*: Smart monitoring devices are optional at additional cost.
![tools-green tools-green](https://cosysolar.com/wp-content/uploads/elementor/thumbs/tools-green-qb1e7r4s34rw7gcn5epmnf1ysb82qqj37lvsrron6w.png)
TECHNICAL SPECIFICATION
Input Data(DC) | |
Recommended Input Power Range(STC) | (180W-550W+)*2 |
Max.DC Input(V) | 60V |
Isc PV (Absolute Max.)(A) | 25A |
Operating Range(V) | 16V-60V |
Max.lnput Current(A) | 14A*2 |
MPPT Voltage Range(V) | 22V-48V |
Output Data(AC) | |
Normal Voltage(Vac) | 189-260V |
Current(Max.continuous)(A) | 3.63A |
Frequency(Hz) | 47.5-52.5HZ/57.5-62.5Hz |
Power(Max.continuous)(W) | 800W |
Power Factor/Rated(default) | +/- 0.90 |
Total Harmonic Distortion | <3% |
Maximum Units Per Branch (12AWG Cable) | 7Units |
Efficiency | |
Peak Inverter Efficiency | 96.50% |
MPPT Efficiency | 99.90% |
Nighttime Power Consumption | <100mW |
Features | |
Communication | PLCC(Power Line Carrier Communication)WiFi |
Compliance | VDE-AR-N 41051EC/EN61000IEC/EN62109-1/2EN50549-12019.TOR 2019.C10/11:2019.UTEC15-712-1:2013VFR2019 |
Warranty | 15 years(20 years optional) |
Others | |
Ingress Protection(lP) | IP67 |
Protective Class | Classe l |
Temperature ( C) | -40°Cto+65°C |
Relative Humidity | 0%-98% |
Overvoltage Category | OVCIII (AC Main)OVCII (PV) |
Inverter Isolation | High Frequency lsolated |
Weight | 3.8kg |
Dimensions(W*H*D) | 264 mm*194 mm*35.5mm |
